Equipment

Temix, focused into provide turn-key systems, designs and manufactures standard and customized satellite communication equipments suitable for both Fixed Stations and Transportable Systems, with a complete product line including Block Up-Converters, Block Down-Converters, TLT, Beacon Receivers, Redundant Switchover Units, Solid State Power Amplifiers, Switching Matrix, Audio/Video Products (Encoders MPEG2 & MPEG4 H.264 SD/HD), DVB-S/S2 L-band Modulators, Uplink Power Control, Antenna Control Units and customized Equipment on request.

System Equipments

 Antenna Control Systems: A complete line of Antenna Controllers is suitable for both Fixed Earth Stations and Mobile Systems (DSNG, Flyaway, Terminals). Main features include full 2/3-axes control, auto­matic Stow & Deploy, GPS & Inclinometer, Limit Switches, Step-Track, Program Track & Memory Track including TLE & Intelsat 11 Parameters.

 Beacon Receiver: The Beacon Receiver is designed to track and measure pilots or beacons of all known commercial satellites. It is particularly suited to track satellite beacons in earth stations using large antenna requiring good boresight alignment and stable uplink power.

 DUAL Feed Combiner: The Dual Feed Controller SWI-TOX-2-NL-A is designed to feed one antenna with two modems (also different type) and/or to feed two antennas for dual satellite transmis­sion. The Dual Feed Controller includes two transmission chains combined through a switchover board operated from front panel.

 Redundant Switchover Units: The Switch Over Unit is a fully programmable 1:N protection switch providing com­plete redundancy for prime and backup equipments.

 Test Loop Translators: The Test Loop Translator is designed to Translate the Up-link Frequency Band into the Receive L-Band Frequency for monitoring and measurement of the transmitted signal. Available with Ku & C-band Inputs.

 Up Power Link Control: Up Power Link Control (UPC) unit is the state of the art solution to detect the link loss due to weather conditions measuring the beacon signal or a reference carrier and automatically controls the Up Link Power through Amplifiers/Attenuators in order to compensate the link losses. Available with Ka, Ku, C and L-band Inputs



Frequency Coverters

 L-band Block Up & Down Converters: The Ku Block Up/Down Converter,  Ka-Band Block Up/Down Converter, and the C-Band Block Up/Down Converter are a high cost-effective solution for sa­tellite communication in the Ka/Ku/C-band with L-Band Interface (up to 4 converters in the same 1U chassis)

 Multi LO PLL LNB: In Ku-band are available in 2, 3 or 4 switchable LO, or with two (high and low band) ouputs.

 IF70/140MHz – L-band Up & Down Converters: L-band Up/Down Converters are a high cost effective solution for sa­tellite communicationwith IF (70/140MHz) interface.

 IF (70/140MHz) – RF (C & Ku-band) Up & Down Converters: Temix Frequency ConverterSeries is a high cost effective solution for satelli­te communication in the C-band & Ku-band with IF (70/140MHz) Interface



Power Amplifiers

 Low-Medium Power in Ku Band: 16W/20W/25W , 40-50W and 60W/80W/100W GaN Ku-band BUC

 Medium-High Power in Ku Band: 150W/200W 250W/300W/350W GaN Ku-band BUC

 Low Medium Power in C Band: 20W/40W and 80W/100W GaN C-band BUC

 Medium-High Power in C Band: 150W/200W and 300W/400W GaN C-band BUC

Baseband (Encoders & Modulators)

 DVB-S/S2 L-Band Modulator: The Broadcast Satellite Modulator is designed for operation in Digital Video Broadcast (DVB) and generic data transmission applications. It provides programmable datarates up to 30 Msps in DVB‑S, DVB-S2 and DVB-DSNG modes and QPSK, 8QPSK, 16APSK, 32APSK Modulation schemes.

 MPEG2 HD/SD and MPEG4 H.264 HD/SD 4:2:2/4:2:0 Encoder: The integration between the MPEG2 HD/SD Encoder, the MPEG4-H264 HD/SD Encoder and the DVB-S/S2 modulator guarantees the most flexible system, lightweigth andeasy to carry and to setup.This high level Broadcasting Encoder features both 4:2:2/4:2:0 Chroma Format(10/8bit), Ultra Low Latency (150ms)

 MPEG2 & MPEG4 4:2:0 HD/SD Encoder: The integration between the MPEG2 HD Encoder and the MPEG4-H264 HD Encoder guarantees the most flexible system, lightweigth and easy to carry and to setup. This high level Broadcasting Encoder features both 4:2:0 Chroma Format (8bit)

 MPEG2 HD/SD and MPEG4 H.264 HD/SD 4:2:2/4:2:0 Decoder and IRD: The MPEG2/MPEG4 HD/SD Decoder features both 4:2:2/4:2:0 Chroma Format(10/8bit); The MPEG2/MPEG4 HD/SD IRD features both 4:2:2/4:2:0 Chroma Format(10/8bit) and BISS Encryption

 MPEG2 HD/SD and MPEG4 H.264 HD/SD 4:2:2/4:2:0 Encoder with DVB-S/S2 L-Band Modulator: The integration between the MPEG2 HD/SD Encoder, the MPEG4-H264 HD/SD Encoderand the DVB-S/S2 modulator guarantees the most flexible system, lightweigth andeasy to carry and to setup. This high level Broadcasting Encoder features both 4:2:2/4:2:0 Chroma Format(10/8bit), Ultra Low Latency (150ms) and BISS Encryption. DVB-S/S2 Modulator QPSK, 8PSK, 16APSK, 32APSK.
